Performance

Standard

Elite

Connector

Mode

Endface

IL(max) (dB)

RL(min) (dB)

IL(max) (dB)

RL(min) (dB)

MPO/MTP

SM

12F/APC

≤0.70

≥60

≤0.35

≥60

24F/APC

≤0.75

≥60

≤0.35

≥60

48F/APC

≤0.75

≥60

MM

12F/PC

≤0.50

≥20

≤0.35

≥20

24F/PC

≤0.50

≥20

≤0.35

≥20

48F/PC

≤0.50

≥20

Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1300nm;
2.Standard conformance: GR-326,GR-1435.

Environment Conditions
