Performance

Standard

Elite

Connector

Mode

Endface

IL(max) (dB)

RL(min) (dB)

IL(max) (dB)

RL(min) (dB)

MPO/MTP

SM

12F/APC

≤0.70

≥60

≤0.35

≥60

24F/APC

≤0.75

≥60

≤0.35

≥60

48F/APC

≤0.75

≥60

MM

12F/PC

≤0.50

≥20

≤0.35

≥20

24F/PC

≤0.50

≥20

≤0.35

≥20

48F/PC

≤0.50

≥20

Note:
1.Test wavelength:SM@1310/1550nm,MM@850/1300nm;
2.Standard conformance: GR-326,GR-1435.

Mechanical Properties

Item

Criteria

Conformance

IL After 50 Matings

MPO/MTP

≤0.3dB

GR-1435

IL After 500 Matings

LC/SC/FC/ST

≤0.2dB

IEC 61300-2-2

Min Bend Radius (Dynamic)

20*OD (Cable Diameter)

Min Bend Radius (Static )

15*OD (Cable Diameter)

Environment Conditions

Item

Criteria

Conformance

Operation Temperature

-40~60°C

IEC 61753-1

Storage Temperature

-45~85°C
